CAJ0234 TAIWAN CALIBRE Universal Ratcheting Punch

CAJ0234 TAIWAN CALIBRE Universal Ratcheting Punch

Hollow hole punch sets

Hollow hole punch sets are used to precisely punch bumper holes for parking sensors. Moreover, they ensure clean cuts. Additionally, selecting the right size prevents bumper damage. Select the correct size punch for the vehicle, install the punch and die set, then use the 3/8" drive with drill to complete a clean hole without damaging the bumper.

Material:

  • CR-V Steel

Feature:

  • The Press-it hole puncher kit efficiently punches holes into bumpers to mount parking sensors. Moreover, it ensures accuracy and prevents damage. Additionally, it provides a reliable solution for various vehicle models.
  • The size of the holes is different from vehicle to vehicle. Previously the holes were drilled by stepped drill bits.
  • The problem is, that the bumper is unusable if the hole is too deep.

Contents:

  • 1 x 2-piece, Ø18.2 mm for VW/Seat
  • 1 x 2-piece, Ø18 mm BMW/Skoda
  • 1 x 2-piece, Ø18.4 mm for VW
  • 1 x 2-piece, Ø18.6 mm for VW
  • 1 x 2-piece, Ø24.0 mm for Opel/Vauxhall
  • 1 x 2-piece, Ø26.0 mm for VW/Seat
  • 1 x 2-piece, Ø26.5 mm for
  • 1 x 2-piece, Ø26.7 mm for VW/Skoda
  • 1 x 2-piece, Ø27.4 mm for
  • 1 x 2-piece, Ø28.1 mm for Skoda
  • 1 x 2-piece, Ø29.3 mm for
  • 1 x 2-piece, Ø32.0 mm for BMW
  • 1 x 2-piece, Ø32.5 mm for BMW
  • 1 x 2-piece, Ø34.4 mm for BMW
  • 1 x 2-piece, Ø37.4 mm for
  • 1 x hole punch Ø38.9 mm for VW (PSA) (without centering mandrel, as the parking steering assistant sensor is mounted at an angle)
  • 1 x hole punch drive, 3/8-inch with ball bearing
  • 1 x drill bit, Ø10 mm
Packaging:
  • 1Set/Blow Mould Case
  • 5Set/15/16kgs/2’
